Maintenance2303−1/A1
Winterthur Gas & Diesel Ltd.
4/ 12
3
4
10
5
II - II
II
WCH02292
II
II
I - I
9
2
5
1
2
7 8
8 6
1
Fig. 6
3
Fig. 6: Gland Box, Overview
1 Cylinder Block 6 Inner Bolt M16x100
2 Gland box housing, 2-part 7 Outer Bolt M16x100
3 Bolt M12x55 8 Locking Plate
4 Dowel Pins 9 Spring Dowel Pin
5 Support 10 O-Rings
2014
Replace, Assembling, Wear Measurement
