Xerox WorkCentre 5022 Service Manual

06/2014
7-4
WC 5022/5024
7.1.1 Plug/Jack Location List
Version 1.0
Wiring Data
P/J205 7 7 Tray 1 Feed Clutch
P/J206 4 4 MSI Feed Clutch
P/J207 11 13 ESS/MCU PWB (to Toner Dispense Motor)
P/J208 7 2 Invert Motor
P/J209 11 7 ESS/MCU PWB (to Nohad Fan)
P/J220A 12 1 Tray 4 Feed/Lift Up Motor (2TM)
P/J220B 12 1 Tray 3 Feed/Lift Up Motor (2TM)
P/J220C 9 1 Tray 2 Feed/Lift Up Motor (1TM)
J352 14 3 Connector (Connect to P5)
P353 14 4 Connector (Connect to J2)
P/J400 11 16 ESS/MCU PWB
P/J401 11 14 ESS/MCU PWB
P/J402 11 12 ESS/MCU PWB
P/J403 11 9 ESS/MCU PWB
P/J405 11 8 ESS/MCU PWB
P/J406 11 11 ESS/MCU PWB
P/J407 11 10 ESS/MCU PWB
P/J409 11 15 ESS/MCU PWB
P/J410 11 18 ESS/MCU PWB
P/J411 11 19 ESS/MCU PWB
P/J412 11 17 ESS/MCU PWB
P413 11 21 ESS/MCU PWB (Connect to J413)
J413 9 8 Connector (Connect to P413)(1TM)
P413C 10 8 STM PWB (Connect to J413C)(1TM)
J413C 12 12 Connector (Connect to P413C)(2TM)
P/J414 11 20 ESS/MCU PWB
P/J415 11 1 ESS/MCU PWB
P/J420 11 4 ESS/MCU PWB
P421 11 5 ESS/MCU PWB (Connect to J421)
J421 2 18 Connector (Connect to P421)
P/J422 11 3 ESS/MCU PWB
P425 11 25 ESS/MCU PWB (Connect to J425)
J425 14 2 NET I/F PWB (Connect to P425)
P441 11 22 ESS/MCU PWB (Connect to J441)
J441 14 9 Connector (Connect to P441)
P442 14 10 Connector (Connect to J442)
J442 11 23 ESS/MCU PWB (Connect to P442)
J443 11 24 ESS/MCU PWB
J444 14 1 NET I/F PWB
P/J445 11 2 ESS/MCU PWB
P/J500 7 1 HVPS
Table 1 Plug/Jack Location List
P/J Fig Item Remarkes (where to Connect)
P/J510 8 6 LVPS
P/J511 8 5 LVPS
P/J512 8 4 LVPS
P/J513 8 3 LVPS
P/J541 13 2 2TM PWB
P/J541C 10 1 STM PWB
P/J548 13 1 2TM PWB
P/J548C 10 6 STM PWB
P/J549 13 7 2TM PWB
P/J549C 10 5 STM PWB
P/J552 13 8 2TM PWB
P/J552C 10 7 STM PWB
P/J554 13 3 2TM PWB
P/J600 4 9 Fusing Unit (4pin)
P/J601 4 5 Connector (5pin)
P/J602 4 8 Connector (3pin)
P/J615 5 8 ATC Sensor
P/J620 5 4 Connector
P/J661A 12 8 Connector (2TM)
P/J661B 12 9 Connector (2TM)
P/J661C 9 5 Connector (1TM)
P/J700 3 7 CCD PWB
P/J721 3 2 Carriage Motor
P/J722 3 1 IIT Regi. Sensor
P/J723 3 13 Platen Open Sensor
P/J725 3 12 Platen Angle Sensor
P/J726 3 14 APS Sensor 1
P/J740 3 11 UI PWB
P/J751 2 9 DADF PWB
P/J752 2 8 DADF PWB
P/J753 2 7 DADF PWB
P/J754 2 4 DADF PWB
P/J756 2 5 DADF PWB (to Exit Nip Release Solenoid)
P/J758 2 6 DADF PWB
P/J759 2 3 DADF PWB
P/J760 2 2 DADF PWB
P/J761 2 1 DADF PWB
P762 2 11 DADF PWB
P763 2 10 DADF PWB
P/J764 1 3 Document Tray Size Sensor 1
P/J765 1 4 Document Tray Size Sensor 2
Table 1 Plug/Jack Location List
P/J Fig Item Remarkes (where to Connect)

Xerox WorkCentre 5022 Specifications

General

Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Duplex Printing	Manual
Paper Sizes	A3, A4, A5, B4, B5
Memory (Standard)	128 MB
Print Technology	Laser
Print Speed	Up to 22 ppm
Print Resolution	600 x 600 dpi
Copy Speed	Up to 22 cpm
Operating System Compatibility	Windows, Mac
First Page Out Time (Copy)	8 seconds
