Effect parameter list
345
Appendix
Appendix
43: 2Delay (DELAY L,R)
1 Dry/Wet Balance D63>W ~ D=W ~ D<W63 Balance of the dry sound and effect sound
2 Delay Time L 0.1~1480ms Length of left channel delay
3 Delay Time R 0.1~1480ms Length of right channel delay
4 Feedback Time 1 0.1~1480ms Length of feedback delay 1
5 Feedback Time 2 0.1~1480ms Length of feedback delay 2
6 Feedback Level -63~+63 Amount of feedback
7 Feedback High Damp 0.1~1.0 High range attenuation (lower values cause the high range to decay faster)
8 EQ Low Frequency 32Hz~2.0kHz Frequency at which the EQ will boost/cut the low range
9 EQ Low Gain -12~+12dB Gain with which the EQ will boost/cut the low range
10 EQ High Frequency 500Hz~16.0kHz Frequency at which the EQ will boost/cut the high range
11 EQ High Gain -12~+12dB Gain with which the EQ will boost/cut the high range
44: Echo (ECHO)
1 Dry/Wet Balance D63>W ~ D=W ~ D<W63 Balance of the dry sound and effect sound
2 Delay Time L1 0.1~740ms Length of first delay of left channel
3 Feedback Level L -63~+63 Amount of feedback for left channel
4 Delay Time R1 0.1~740ms Length of first delay of right channel
5 Feedback Level R -63~+63 Amount of feedback for right channel
6 Feedback High Damp 0.1~1.0 High range attenuation (lower values cause the high range to decay faster)
7 Delay Time L2 0.1~740ms Length of second delay of left channel
8 Delay Time R2 0.1~740ms Length of second delay of right channel
9 Delay Level 2 0~127 Volume of second delay
10 EQ Low Frequency 32Hz~2.0kHz Frequency at which the EQ will boost/cut the low range
11 EQ Low Gain -12~+12dB Gain with which the EQ will boost/cut the low range
12 EQ High Frequency 500Hz~16.0kHz Frequency at which the EQ will boost/cut the high range
13 EQ High Gain -12~+12dB Gain with which the EQ will boost/cut the high range
45: X-Delay (CROSS DELAY)
1 Dry/Wet Balance D63>W ~ D=W ~ D<W63 Balance of the dry sound and effect sound
2 Delay Time L>R 0.1~740ms Delay time from left (input) to right (output)
3 Delay Time R>L 0.1~740ms Delay time from right (input) to left (output)
4 Feedback Level -63~+63 Amount of feedback
5 Input Select “L, R, L&R” Input select
6 Feedback High Damp 0.1~1.0 High range attenuation (lower values cause the high range to decay faster)
7 EQ Low Frequency 32Hz~2.0kHz Frequency at which the EQ will boost/cut the low range
8 EQ Low Gain -12~+12dB Gain with which the EQ will boost/cut the low range
9 EQ High Frequency 500Hz~16.0kHz Frequency at which the EQ will boost/cut the high range
10 EQ High Gain -12~+12dB Gain with which the EQ will boost/cut the high range
46: Dly+Pan (DELAY+AUTO PAN)
1 Dry/Wet Balance D63>W ~ D=W ~ D<W63 Balance of the dry sound and effect sound
2 Delay Time 0.1~740ms Delay time
3 Feedback Level -63~+63 Amount of feedback
4 Feedback High Damp 0.1~1.0 High range attenuation (lower values cause the high range to decay faster)
5 Auto Pan Speed 0.00Hz~39.7Hz Auto pan frequency
6 Auto Pan Depth 0~127 Panning depth
7 EQ Frequency 90Hz~10.0kHz Frequency at which the EQ will boost/cut the mid range
8 EQ Gain -12~+12dB Gain with which the EQ will boost/cut the mid range
9 EQ Width 1.0~12.0 Width of the mid range area which the EQ will boost/cut
47: Hall (HALL), 48: Room (ROOM), 49: Stage (STAGE), 50: Plate (PLATE)
1 Dry/Wet Balance D63>W ~ D=W ~ D<W63 Balance of the dry sound and effect sound
2 Reverb Time 0.3~30.0s Reverb length
3 Diffusion 0~10 Spread of the reverb
4 Initial Delay 0.1~99.3ms Delay time until the early reflections
5 HPF Cutoff Freq Thru~8.0kHz Frequency at which the high pass filter will cut the low range
6 LPF Cutoff Freq 1.0kHz~Thru Frequency at which the low pass filter will cut the high range
7 Reverb Delay 0.1~99.3ms Delay time from the early reflections until the reverberation
8 Density 0~4 Density of the reverberation
9 Er/Rev Balance E63>R ~ E=R ~ E<R63 Level balance of the early reflections and the reverberation
10 Feedback High Damp 0.1~1.0 High range attenuation (lower values cause the high range to decay faster)
11 Feedback Level -63~+63 Amount of feedback for the initial delay
