NOTE:
If the specified clutch lever free play cannot be
obtained on the handlebar side of the cable, use
the adjusting nut on the engine side.
▲▲▲▲▲▲▲▲▲ ▲ ▲▲▲▲▲▲▲▲▲ ▲ ▲▲▲▲ ▲ ▲▲▲▲ ▲▲▲
3. Remove:
• Left side panel
• Right side panel
Refer to “FUEL TANK” on page 7-1.
▼▼▼▼▼▼▼▼▼ ▼ ▼▼▼▼▼▼▼▼▼ ▼ ▼▼▼▼ ▼ ▼▼▼▼ ▼▼▼
Engine side
a. Slide back the rubber cover “1”.
b. Loosen the locknut “2”.
c. Turn the adjusting nut “3” in direction “a” or “b”
until the specified clutch lever free play is ob-
tained.
d. Slide the rubber cover to its original position.
e. Tighten the locknut.
▲▲▲▲▲▲▲▲▲ ▲ ▲▲▲▲▲▲▲▲▲ ▲ ▲▲▲▲ ▲ ▲▲▲▲ ▲▲▲
4. Install:
• Right side panel
• Left side panel
Refer to “FUEL TANK” on page 7-1.
EAS20960
REPLACING THE AIR FILTER ELEMENT
1. Remove:
• Air filter case cover “1”
2. Remove:
• Air filter element “1”
3. Check:
• Air filter element
Damage → Replace.
NOTE:
The air filter needs more frequent service if you
are riding in unusually wet or dusty areas.
4. Install:
• Air filter element
• Air filter case cover
CAUTION:
ECA3D81015
Never operate the engine without the air filter
element installed. Unfiltered air will cause
rapid wear of engine parts and may damage
the engine. Operating the engine without the
air filter element will also affect throttle body
synchronization, leading to poor engine per-
formance and possible overheating.
NOTE:
When installing the air filter element into the air
filter case, make sure that the sealing surfaces
are aligned to prevent any air leaks.
Direction “a”
Clutch cable free play is increased.
Direction “b”
Clutch cable free play is decreased.
1
2
a
b
3
1
2
a
b
1
1
To Next Page
