COOLING SYSTEM
8-31
EAS27320
TROUBLESHOOTING
The radiator fan motor fails to turn.
NOTE:
• Before troubleshooting, remove the following part(s):
1. Rider seat
2. Tool kit tray
3. Fuel tank
4. Headlight lens unit
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the fuses.
(Main, ignition and radiator fan mo-
tor)
Refer to “CHECKING THE FUS-
ES” on page 8-87.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-87.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the main switch/immobilizer unit.
4. Check the radiator fan motor.
Refer to “CHECKING THE RADIA-
TOR FAN MOTOR” on page 8-100.
Replace the radiator fan motor.
5. Check the radiator fan motor relay.
Refer to “CHECKING THE RE-
LAYS” on page 8-91.
Replace the radiator fan motor relay.
6. Check the coolant temperature sen-
sor.
Refer to “CHECKING THE COOL-
ANT TEMPERATURE SENSOR”
on page 8-100.
Replace the coolant temperature sensor.
7. Check the entire cooling system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-29.
Properly connect or repair the cooling sys-
tem’s wiring.
Replace the ECU.
To Next Page
