OIL PUMP
5-71
EAS24910
OIL PUMP
Removing the oil/water pump assembly
Order Job/Parts to remove Q’ty Remarks
Crankcase
Separate.
Refer to “CRANKCASE” on page 5-65.
1 Drain cock 1
2 Relief valve assembly 1
3 Oil/water pump assembly 1
4 Dowel pin 2
5 Joint pipe 1
6 Oil pump housing 1
7 Bearing 1
8Pin 2
9 Oil pump outer rotor 1
10 Oil pump inner rotor 1
11 Pin 1
12 Water pump housing 1
For installation, reverse the removal proce-
dure.
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
24 Nm (2.4 m
•
kg, 17 ft
•
Ib)
T
R
.
.
24 Nm (2.4 m
•
kg, 17 ft
•
Ib)
LS
8
8
6
9
10
11
12
7
4
5
1
2
3
New
New
New
New
New
LS
LS
LS
New
LS
To Next Page
