CAMSHAFTS
5-11
EAS23740
CAMSHAFTS
Removing the cylinder head covers
Order Job/Parts to remove Q’ty Remarks
Engine Refer to “ENGINE REMOVAL” on page 5-1.
1 Tappet cover 4
2 Front cylinder head cover bolt 2 l = 55 mm (2.17 in)
3 Front cylinder head cover bolt 3 l = 45 mm (1.77 in)
4 Front cylinder head cover bolt 2 l = 30 mm (1.18 in)
5 Front cylinder head cover bracket 1
6 Rear cylinder head cover bolt 7 l = 45 mm (1.77 in)
7 Rear cylinder head cover bolt 2 l = 55 mm (2.17 in)
8 Rear cylinder head cover bolt 2 l = 30 mm (1.18 in)
9 Rear cylinder head cover bracket 1
10 Front cylinder head cover 1
11 Rear cylinder head cover 1
12 Cylinder head cover gasket 2
13 Dowel pin 4
For installation, reverse the removal proce-
dure.
1
8
6
8
7
9
7
6
6
1
11
12
13
13
1
4
3
2
5
2
3
3
1
4
10
12
13
13
New
New
New
New
New
New
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
6 Nm (0.6 m
•
kg, 4.3 ft
•
Ib)
T
R
.
.
6 Nm (0.6 m
•
kg, 4.3 ft
•
Ib)
New
New
LS
LS
LS
LS
LS
LS
FWD
