GENERAL CHASSIS
4-2
Removing the headlight
Order Job/Parts to remove Q’ty Remarks
1 Turn signal light bracket cover 1
2 Headlight lens unit 1
3 Headlight coupler 1 Disconnect.
4 Turn signal light coupler 2 Disconnect.
5 Meter assembly coupler 3 Disconnect.
6 Main switch coupler 2 Disconnect.
7 Plastic band bracket 1
8 Headlight body 1
For installation, reverse the removal proce-
dure.
3
4
2
7
1
8
5
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
6
To Next Page
