Yamaha XVS1300A 2007 - Front Fork

FRONT FORK
4-47
EAS22950
FRONT FORK
Removing the front fork legs
Order Job/Parts to remove Q’ty Remarks
The following procedure applies to both of
the front fork legs.
Windshield bracket (left and right)
For XVS13CT only
Refer to “GENERAL CHASSIS” on page
4-1.
Headlight body
Refer to “GENERAL CHASSIS” on page
4-1.
Front wheel Refer to “FRONT WHEEL” on page 4-7.
Rear handlebar holder Refer to “HANDLEBAR” on page 4-43.
1 Brake hose guide 2
2 Reflector bracket 2
3 Front fender 1
4 Main switch coupler 2 Disconnect.
5 Upper bracket pinch bolt 2 Loosen.
6 Cap bolt 1 Loosen.
7 Steering stem nut 1
8 Upper bracket 1
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
T
R
.
.
18 Nm (1.8 m
•
kg, 13 ft
•
Ib)
T
R
.
.
110 Nm (11.0 m
•
kg, 80 ft
•
lb)
1
2
1
2
3
5
8
7
5
4
9
10
11
12
13
6
14
