ELECTRICAL SPECIFICATIONS
2-12
EAS20310
ELECTRICAL SPECIFICATIONS
Voltage
System voltage 12 V
Ignition system
Ignition system Transistorized coil ignition (digital)
Advancer type Electric
Ignition timing (B.T.D.C.) 5.0 °/1000 r/min
Engine control unit
Model/manufacturer FUA0014/MITSUBISHI
Ignition coil
Model/manufacturer 2JN/MORIC
Minimum ignition spark gap 6.0 mm (0.24 in)
Primary coil resistance 2.16–2.64 Ω
Secondary coil resistance 8.64–12.96 kΩ
Spark plug cap
Material Resin
Resistance 10.0 kΩ
Lean angle sensor output voltage
Less than 65° 0.4–1.4 V
More than 65° 3.7–4.4 V
AC magneto
Model/manufacturer F3D8/MORIC
Standard output 14.0 V 32.9 A 5000 r/min
Standard output 14.0 V 460 W 5000 r/min
Stator coil resistance 0.112–0.168 Ω
Rectifier/regulator
Regulator type Semiconductor, short circuit
Model/manufacturer FH012AA/SHINDENGEN
Regulated voltage (DC) 14.2–14.8 V
Rectifier capacity (DC) 50.0 A
Withstand voltage 40.0 V
Battery
Model YTX20L-BS
Voltage, capacity 12 V, 18.0 Ah
Manufacturer GS YUASA
Ten hour rate amperage 1.80 A
Headlight
Bulb type Halogen bulb
Bulb voltage, wattage × quantity
Headlight 12 V, 60 W/55.0 W × 1
Auxiliary light 12 V, 5.0 W × 1
