FUEL PUMP SYSTEM
8-67
EAS27570
TROUBLESHOOTING
The fuel pump fails to operate.
NOTE:
• Before troubleshooting, remove the following part(s):
1. Rider seat
2. Tool kit tray
3. Fuel tank
4. Battery box
5. Headlight lens unit
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the fuses.
(Main, ignition and fuel injection
system)
Refer to “CHECKING THE FUS-
ES” on page 8-87.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-87.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the main switch/immobilizer unit.
4. Check the engine stop switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
The engine stop switch is faulty. Replace
the right handlebar switch.
5. Check the relay unit (fuel pump re-
lay).
Refer to “CHECKING THE RE-
LAYS” on page 8-91.
Replace the relay unit.
6. Check the fuel pump.
Refer to “CHECKING THE FUEL
PUMP BODY” on page 7-4.
Replace the fuel pump.
7. Check the diode 2.
Refer to “CHECKING THE DI-
ODES” on page 8-93.
Replace the diode 2.
To Next Page
