TIGHTENING TORQUES
2-20
EAS20350
CHASSIS TIGHTENING TORQUES
Item
Thread
size
Q’ty Tightening torque Remarks
Engine bracket bolt (right front
upper side)
M10 2 48 Nm (4.8 m·kg, 35 ft·lb)
Engine bracket bolt (left front up-
per side)
M10 2 48 Nm (4.8 m·kg, 35 ft·lb)
Engine mounting bolt (front upper
side)
M12 4 30 Nm (3.0 m·kg, 22 ft·lb)
Engine mounting nut (front lower
side)
M12 1 88 Nm (8.8 m·kg, 64 ft·lb)
Engine mounting nut (rear upper
side)
M12 1 88 Nm (8.8 m·kg, 64 ft·lb)
Engine bracket bolt (rear upper
side)
M10 2 48 Nm (4.8 m·kg, 35 ft·lb)
Engine mounting nut (rear lower
side)
M12 1 88 Nm (8.8 m·kg, 64 ft·lb)
Engine bracket bolt (rear lower
side)
M10 2 48 Nm (4.8 m·kg, 35 ft·lb)
Down tube and frame bolt M10 4 48 Nm (4.8 m·kg, 35 ft·lb)
Ignition coil bolt M6 4 7 Nm (0.7 m·kg, 5.1 ft·lb)
Ignition coil bracket bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Rear shock absorber assembly
lower nut
M10 1 48 Nm (4.8 m·kg, 35 ft·lb)
Rear shock absorber assembly
upper nut
M10 1 48 Nm (4.8 m·kg, 35 ft·lb)
Pivot shaft nut M16 1 85 Nm (8.5 m·kg, 61 ft·lb)
Relay arm and frame nut M10 1 48 Nm (4.8 m·kg, 35 ft·lb)
Connecting arm and relay arm
nut
M12 1 59 Nm (5.9 m·kg, 43 ft·lb)
Connecting arm and swingarm
nut
M12 1 59 Nm (5.9 m·kg, 43 ft·lb)
Drive belt upper guard bolt M6 3 7 Nm (0.7 m·kg, 5.1 ft·lb)
Drive belt lower guard and swing-
arm bolt
M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Drive belt lower guard plate bolt
(upper side)
M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Drive belt lower guard plate bolt
(lower side)
M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Upper bracket pinch bolt M8 2 20 Nm (2.0 m·kg, 14 ft·lb)
Steering stem nut M22 1 110 Nm (11.0 m·kg, 80 ft·lb)
Lower ring nut (initial tightening
torque)
M30 1 52 Nm (5.2 m·kg, 37 ft·lb)
See
NOTE.
Lower ring nut (final tightening
torque)
M30 1 18 Nm (1.8 m·kg, 13 ft·lb)
See
NOTE.
LT
LT
LT
LT
LT
