Yamaha XVS1300A 2007 - Page 46

TIGHTENING TORQUES
2-21
Lower bracket pinch bolt M8 4 23 Nm (2.3 m·kg, 17 ft·lb)
Front fork cap bolt M38 2 23 Nm (2.3 m·kg, 17 ft·lb)
Damper rod bolt M12 2 30 Nm (3.0 m·kg, 22 ft·lb)
Lower front fork cover bolt M6 4 18 Nm (1.8 m·kg, 13 ft·lb)
Main switch and upper bracket
bolt
M8 2 30 Nm (3.0 m·kg, 22 ft·lb)
Rear handlebar holder nut M12 2 32 Nm (3.2 m·kg, 23 ft·lb)
Front handlebar holder bolt M8 4 28 Nm (2.8 m·kg, 20 ft·lb)
Front brake master cylinder hold-
er bolt
M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Front brake lever bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Front brake lever nut M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Clutch lever holder bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Grip end M16 2 23 Nm (2.3 m·kg, 17 ft·lb)
Front brake hose union bolt M10 3 30 Nm (3.0 m·kg, 22 ft·lb)
Front brake hose holder and low-
er bracket bolt
M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Front brake hose holder bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Front brake hose joint bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Front fender bolt M8 4 23 Nm (2.3 m·kg, 17 ft·lb)
Front brake hose guide bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Headlight bracket bolt M8 2 23 Nm (2.3 m·kg, 17 ft·lb)
Headlight body bolt M6 4 7 Nm (0.7 m·kg, 5.1 ft·lb)
Front turn signal light bracket bolt M8 2 23 Nm (2.3 m·kg, 17 ft·lb)
Front turn signal light nut M10 2 11 Nm (1.1 m·kg, 8.0 ft·lb)
Air temperature sensor screw M5 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Meter assembly bolt M8 2 23 Nm (2.3 m·kg, 17 ft·lb)
Meter assembly cover bracket
bolt
M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Meter assembly cover bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Fuel cock screw M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Fuel pump bolt M5 6 6 Nm (0.6 m·kg, 4.3 ft·lb)
Fuel sender bolt M6 2 8 Nm (0.8 m·kg, 5.8 ft·lb)
Fuel tank bracket bolt M8 2 23 Nm (2.3 m·kg, 17 ft·lb)
Sub-fuel tank bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Seat lock bracket bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Front wheel axle M16 1 59 Nm (5.9 m·kg, 43 ft·lb)
Front wheel axle pinch bolt M8 1 20 Nm (2.0 m·kg, 14 ft·lb)
Front brake caliper bracket bolt M10 4 40 Nm (4.0 m·kg, 29 ft·lb)
Item
Thread
size
Q’ty Tightening torque Remarks
LT
LT
LT
LT
LT
