Yamaha XVS1300A 2007 - Page 47

TIGHTENING TORQUES
2-22
Front brake caliper bolt M10 4 27 Nm (2.7 m·kg, 19 ft·lb)
Front brake disc bolt M8 12 23 Nm (2.3 m·kg, 17 ft·lb)
Bleed screw (front brake caliper) M7 2 6 Nm (0.6 m·kg, 4.3 ft·lb)
Rear wheel axle nut M10 1 150 Nm (15.0 m·kg, 110 ft·lb)
Drive belt adjusting locknut M8 2 16 Nm (1.6 m·kg, 11 ft·lb)
Rear brake caliper bolt M10 2 27 Nm (2.7 m·kg, 19 ft·lb)
Rear brake disc bolt M8 6 23 Nm (2.3 m·kg, 17 ft·lb)
Bleed screw (rear brake caliper) M7 1 6 Nm (0.6 m·kg, 4.3 ft·lb)
Rear brake hose union bolt M10 2 30 Nm (3.0 m·kg, 22 ft·lb)
Rear brake hose guide bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Rear brake hose holder bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Rear wheel pulley nut M12 5 95 Nm (9.5 m·kg, 68 ft·lb)
Rear wheel drive hub stud bolt M12 5 30 Nm (3.0 m·kg, 22 ft·lb)
Rear fender bracket, rear fender,
and frame bolt
M8 4 23 Nm (2.3 m·kg, 17 ft·lb)
Passenger seat bracket, rear
fender, and frame bolt
M8 2 16 Nm (1.6 m·kg, 11 ft·lb)
Passenger seat guide, rear fend-
er, and frame bolt
M8 2 16 Nm (1.6 m·kg, 11 ft·lb)
Passenger seat bolt M8 2 16 Nm (1.6 m·kg, 11 ft·lb)
License plate bracket and rear
fender bolt
M6 2 11 Nm (1.1 m·kg, 8.0 ft·lb)
Rear turn signal light nut M10 2 11 Nm (1.1 m·kg, 8.0 ft·lb)
Left side cover bolt M6 1 4 Nm (0.4 m·kg, 2.9 ft·lb)
Relay cover bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Sub-fuel tank cover bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Coolant reservoir cover bolt M6 4 7 Nm (0.7 m·kg, 5.1 ft·lb)
Side panel bolt (left and right) M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Positive battery lead bolt (starter
relay side)
M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Starter motor lead bolt (starter
relay side)
M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Relay bracket and frame bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Battery box bolt M6 4 7 Nm (0.7 m·kg, 5.1 ft·lb)
Sidestand bracket bolt M10 2 56 Nm (5.6 m·kg, 40 ft·lb)
Sidestand switch bolt M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
Sidestand nut M10 1 56 Nm (5.6 m·kg, 40 ft·lb)
Shift rod locknut M6 2 8 Nm (0.8 m·kg, 5.8 ft·lb)
Shift arm bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Brake pedal bracket bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Item
Thread
size
Q’ty Tightening torque Remarks
LS
LT
LS
LT
LT
LT
LT
