CRANKCASE
5-65
EAS25540
CRANKCASE
Removing the oil delivery pipes and timing chains
Order Job/Parts to remove Q’ty Remarks
Engine Refer to “ENGINE REMOVAL” on page 5-1.
Pistons
Refer to “CYLINDERS AND PISTONS” on
page 5-33.
Shift shaft Refer to “SHIFT SHAFT” on page 5-56.
Balancer assemblies
Refer to “BALANCER GEARS” on page
5-58.
1 Oil level switch 1
2 Engine oil drain bolt 1
3 Neutral switch 1
4 Oil delivery pipe 1 1
5 Timing chain guide 2
6 Timing chain 2
7 Coolant delivery pipe 1
8 Speed sensor 1
9 Spacer 1
10 Oil filter cartridge 1
11 Oil delivery pipe 2 1
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
T
R
.
.
17 Nm (1.7 m
•
kg, 12 ft
•
Ib)
T
R
.
.
70 Nm (7.0 m
•
kg, 50 ft
•
lb)
T
R
.
.
15 Nm (1.5 m
•
kg, 11 ft
•
Ib)
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
New
New
New
New
New
New
New
New
New
LS
LT
LT
LS
LS
LT
LT
LS
LT
LT
LT
LT
New
LT
LT
LT
LS
LS
LT
New
1
5
6
2
3
9
4
7
10
11
12
18
17
(4)
(9)
5
6
8
13
14
16
15
T
R
.
.
43 Nm (4.3 m
•
kg, 31 ft
•
Ib)
