ELECTRIC STARTER
5-61
EAS24780
ELECTRIC STARTER
Removing the starter motor
Order Job/Parts to remove Q’ty Remarks
1 Starter motor lead 1 Disconnect.
2 Starter motor 1
For installation, reverse the removal proce-
dure.
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
2
1
