IGNITION SYSTEM
8-4
EAS27140
TROUBLESHOOTING
The ignition system fails to operate (no spark or intermittent spark).
NOTE:
• Before troubleshooting, remove the following part(s):
1. Rider seat
2. Tool kit tray
3. Fuel tank
4. Battery box
5. Headlight lens unit
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
OK →
NG ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the fuses.
(Main and ignition)
Refer to “CHECKING THE FUS-
ES” on page 8-87.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-87.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the spark plugs.
Refer to “CHECKING THE SPARK
PLUGS” on page 3-8.
Regap or replace the spark plug(s).
4. Check the ignition spark gap.
Refer to “CHECKING THE IGNI-
TION SPARK GAP” on page 8-94.
Ignition system is OK.
5. Check the spark plug caps.
Refer to “CHECKING THE SPARK
PLUG CAPS” on page 8-95.
Replace the spark plug cap(s).
6. Check the ignition coils.
Refer to “CHECKING THE IGNI-
TION COILS” on page 8-95.
Replace the ignition coil(s).
7. Check the crankshaft position sen-
sor.
Refer to “CHECKING THE CRANK-
SHAFT POSITION SENSOR” on
page 8-96.
Replace the crankshaft position sen-
sor/stator assembly.
To Next Page
