IGNITION SYSTEM
8-5
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
8. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the main switch/immobilizer unit.
9. Check the engine stop switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the right handlebar switch.
10.Check the neutral switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the neutral switch.
11.Check the sidestand switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the sidestand switch.
12.Check the relay unit (diode).
Refer to “CHECKING THE DI-
ODES” on page 8-93.
Replace the relay unit.
13.Check the lean angle sensor.
Refer to “CHECKING THE LEAN
ANGLE SENSOR” on page 8-96.
Replace the lean angle sensor.
14.Check the entire ignition system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-1.
Properly connect or repair the ignition sys-
tem’s wiring.
Replace the ECU.
To Next Page
