RADIATOR
6-1
EAS26380
RADIATOR
Removing the radiator
Order Job/Parts to remove Q’ty Remarks
Rider seat/Sub-fuel tank cover
Refer to “GENERAL CHASSIS” on page
4-1.
Muffler/Coolant reservoir cover Refer to “ENGINE REMOVAL” on page 5-1.
Fuel tank Refer to “FUEL TANK” on page 7-1.
Coolant
Drain.
Refer to “CHANGING THE COOLANT” on
page 3-16.
1 Rear brake hose guide 1
2 Rear brake hose holder 1
3 Plastic holder 1
4 Coolant reservoir breather hose 1
5 Coolant reservoir hose 1
6 Coolant reservoir cap 1
7 Coolant reservoir 1
8 Radiator cap 1
9 Radiator fan motor coupler 1 Disconnect.
10 Radiator cover 1
LS
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
New
New
T
R
.
.
2 Nm (0.2 m
•
kg, 1.4 ft
•
Ib)
LT
LT
2
1
6
5
4
7
12
10
13
16
14
15
11
9
8
(3)
3
To Next Page
