ENGINE REMOVAL
5-1
EAS23710
ENGINE REMOVAL
Removing the muffler and exhaust pipes
Order Job/Parts to remove Q’ty Remarks
1 Coolant reservoir cap cover 1
2
O
2
sensor coupler
1 Disconnect.
3Muffler 1
4Gasket 1
5 Rear cylinder exhaust pipe 1
6Gasket 2
7Gasket 1
8 Front cylinder exhaust pipe 1
9 Muffler bracket 1
10
O
2
sensor
1
11 Coolant reservoir cover 1
For installation, reverse the removal proce-
dure.
6
1
T
R
.
.
4 Nm (0.4 m
•
kg, 2.9 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
44 Nm (4.4 m
•
kg, 32 ft
•
Ib)
T
R
.
.
35 Nm (3.5 m
•
kg, 25 ft
•
Ib)
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
T
R
.
.
53 Nm (5.3 m
•
kg, 38 ft
•
Ib)
New
New
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
9
11
2
3
10
6
(3)
(3)
T
R
.
.
6 Nm (0.6 m
•
kg, 4.3 ft
•
Ib)
New
New
New
New
T
R
.
.
6 Nm (0.6 m
•
kg, 4.3 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
New
5
8
New
4
7
New
