FRONT WHEEL
4-7
EAS21870
FRONT WHEEL
Removing the front wheel and brake discs
Order Job/Parts to remove Q’ty Remarks
NOTE:
Place the vehicle on a suitable stand so that
the front wheel is elevated.
1 Front brake caliper 2
2 Front wheel axle pinch bolt 1 Loosen.
3 Front wheel axle 1
4 Front wheel 1
5Collar 2
6 Front brake disc 2
For installation, reverse the removal proce-
dure.
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
T
R
.
.
40 Nm (4.0 m
•
kg, 29 ft
•
Ib)
T
R
.
.
40 Nm (4.0 m
•
kg, 29 ft
•
Ib)
T
R
.
.
59 Nm (5.9 m
•
kg, 43 ft
•
Ib)
6
5
4
6
5
1
3
2
1
(6)
(6)
LT
LT
LT
To Next Page
