ELECTRICAL SPECIFICATIONS
2-13
Tail/brake light 12 V, 5.0 W/21.0 W × 1
Front turn signal light 12 V, 21.0 W × 2
Rear turn signal light 12 V, 21.0 W × 2
License plate light 12 V, 5.0 W × 1
Meter lighting LED
Indicator light
Neutral indicator light LED
Turn signal indicator light LED
Oil level warning light LED
High beam indicator light LED
Fuel level warning light LED
Coolant temperature warning light LED
Engine trouble warning light LED
Immobilizer system indicator light LED
Electric starting system
System type Constant mesh
Starter motor
Model/manufacturer SM13/MITSUBA
Power output 0.90 kW
Armature coil resistance 0.0100–0.0200 Ω
Brush overall length 12.5 mm (0.49 in)
Limit 5.00 mm (0.20 in)
Brush spring force 7.65–10.01 N (27.54–36.03 oz) (780–1021 gf)
Commutator diameter 28.0 mm (1.10 in)
Limit 27.0 mm (1.06 in)
Mica undercut (depth) 0.70 mm (0.03 in)
Starter relay
Model/manufacturer 2768115-A/JIDECO
Amperage 180.0 A
Coil resistance 4.18–4.62 Ω
Horn
Horn type Plane
Quantity 1 pc
Model/manufacturer HF-12/NIKKO
Maximum amperage 3.0 A
Coil resistance 1.01–1.11 Ω
Performance 108–116 dB/2m
Turn signal relay
Relay type Semi transistor
Model/manufacturer FE246BS/DENSO
Built-in, self-canceling device No
Turn signal blinking frequency 75.0–95.0 cycles/min
Wattage (21,23,27) W × 2
Oil level switch
Model/manufacturer 3D8/YAMATO
Oil level switch resistance (minimum level position) 114.0–126.0 Ω
