ELECTRICAL SPECIFICATIONS
2-14
Oil level switch resistance (maximum level position)484–536 Ω
Fuel sender
Model/manufacturer 3D8/NIPPON SEIKI
Starting circuit cut-off relay
Model/manufacturer G8R-30Y-U3/OMRON
Coil resistance 162.0–198.0 Ω
Headlight relay
Model/manufacturer ACM33211 M05/MATSUSHITA
Coil resistance 86.40–105.60 Ω
Fuel pump relay
Model/manufacturer G8R-30Y-U3/OMRON
Coil resistance 162–198 Ω
Fan motor relay
Model/manufacturer ACM33211 M05/MATSUSHITA
Coil resistance 86.40–105.60 Ω
Coolant temperature sensor
Model/manufacturer K003T20191/MITSUBISHI
Fuses
Main fuse 50.0 A
Headlight fuse 20.0 A
Signaling system fuse 10.0 A
Ignition fuse 15.0 A
Radiator fan fuse 20.0 A
Parking lighting fuse 10.0 A
Fuel injection system fuse 10.0 A
Backup fuse 10.0 A
Reserve fuse 20.0 A
Reserve fuse 15.0 A
Reserve fuse 10.0 A
