CHASSIS SPECIFICATIONS
2-11
Spring stroke K1 0.0–48.0 mm (0.00–1.89 in)
Optional spring available No
Enclosed gas/air pressure (STD) 1200 kPa (170.7 psi) (12.0 kgf/cm²)
Spring preload adjusting positions
Minimum 1
Standard 4
Maximum 9
Swingarm
Swingarm end free play limit (radial) 1.0 mm (0.04 in)
Swingarm end free play limit (axial) 1.0 mm (0.04 in)
Drive belt
Model/manufacturer UBD-0734/GATES CORPORATION
Drive belt slack (on the sidestand) 5.0–7.0 mm (0.20–0.28 in)
Drive belt slack (on a suitable stand) 4.0–6.0 mm (0.16–0.24 in)
