CHASSIS SPECIFICATIONS
2-10
Brake disc deflection limit 0.12 mm (0.0047 in)
Brake pad lining thickness (inner) 6.0 mm (0.24 in)
Limit 0.8 mm (0.03 in)
Brake pad lining thickness (outer) 6.0 mm (0.24 in)
Limit 0.8 mm (0.03 in)
Master cylinder inside diameter 14.00 mm (0.55 in)
Caliper cylinder inside diameter 25.40 mm (1.00 in)
Caliper cylinder inside diameter 30.16 mm (1.19 in)
Recommended fluid DOT 4
Rear brake
Type Single disc brake
Operation Right foot operation
Rear disc brake
Disc outside diameter × thickness 298.0 × 6.0 mm (11.73 × 0.24 in)
Brake disc thickness limit 5.5 mm (0.22 in)
Brake disc deflection limit 0.15 mm (0.0059 in)
Brake pad lining thickness (inner) 5.8 mm (0.23 in)
Limit 0.8 mm (0.03 in)
Brake pad lining thickness (outer) 5.8 mm (0.23 in)
Limit 0.8 mm (0.03 in)
Master cylinder inside diameter 12.7 mm (0.50 in)
Caliper cylinder inside diameter 41.30 mm (1.63 in)
Recommended fluid DOT 4
Steering
Steering bearing type Angular bearing
Lock to lock angle (left) 35.0 °
Lock to lock angle (right) 35.0 °
Front suspension
Type Telescopic fork
Spring/shock absorber type Coil spring/oil damper
Front fork travel 135.0 mm (5.31 in)
Fork spring free length 345.5 mm (13.60 in)
Limit 339.4 mm (13.36 in)
Collar length 183.0 mm (7.20 in)
Installed length 339.4 mm (13.36 in)
Spring rate K1 7.35 N/mm (41.97 lb/in) (0.75 kgf/mm)
Spring stroke K1 0.0–135.0 mm (0.00–5.31 in)
Inner tube outer diameter 41.0 mm (1.61 in)
Optional spring available No
Recommended oil Yamaha fork oil 10WT
Quantity 490.0 cm³ (16.57 US oz) (17.28 Imp.oz)
Level 105.0 mm (4.13 in)
Rear suspension
Type Swingarm (link suspension)
Spring/shock absorber type Coil spring/gas-oil damper
Rear shock absorber assembly travel 48.0 mm (1.89 in)
Spring free length 182.0 mm (7.17 in)
Installed length 166.0 mm (6.54 in)
Spring rate K1 160.00 N/mm (913.60 lb/in) (16.32 kgf/mm)
