Yamaha XVS1300A 2007 - Page 162

REAR BRAKE
4-37
Disassembling the rear brake caliper
Order Job/Parts to remove Q’ty Remarks
1 Brake caliper piston 1
2 Brake caliper piston seal 2
3 Bleed screw 1
For assembly, reverse the disassembly pro-
cedure.
2
1
3
New
T
R
.
.
6 Nm (0.6 m
•
kg, 4.3 ft
•
Ib)
LS
