Yamaha XVS1300A 2007 - Page 196

BELT DRIVE
4-71
4. Tighten:
• Drive pulley cover plate bolt
NOTE:
Tighten the drive pulley cover plate bolts tempo-
rarily, and then tighten them in proper tightening
sequence as shown.
5. Adjust:
• Drive belt slack
Refer to “ADJUSTING THE DRIVE BELT
SLACK” on page 3-23.
a
4
3
2
1
