ENGINE REMOVAL
5-7
Removing the down tube and engine
Order Job/Parts to remove Q’ty Remarks
1 Sub-fuel tank bracket bolt 2
2 Coolant reservoir cover bracket 1
3 Engine mounting nut (front lower side) 1
4 Engine mounting bolt (front lower side) 1
5 Down tube bolt (front side) 2
6 Down tube bolt (rear side) 2
7 Down tube 1
8 Engine mounting nut (rear upper side) 1
9 Engine mounting bolt (rear upper side) 1
10 Engine mounting nut (rear lower side) 1
11 Engine mounting bolt (rear lower side) 1
12 Engine bracket bolt (rear upper side) 2
13 Engine bracket (rear upper side) 1
14 Engine bracket bolt (rear lower side) 2
15 Engine bracket (rear lower side) 1
16 Engine mounting bolt (front left upper side) 2
17 Engine mounting bolt (front right upper side) 2
T
R
.
.
48 Nm (4.8 m
•
kg, 35 ft
•
Ib)
T
R
.
.
48 Nm (4.8 m
•
kg, 35 ft
•
Ib)
T
R
.
.
48 Nm (4.8 m
•
kg, 35 ft
•
Ib)
T
R
.
.
30 Nm (3.0 m
•
kg, 22 ft
•
Ib)
T
R
.
.
88 Nm (8.8 m
•
kg, 64 ft
•
Ib)
T
R
.
.
88 Nm (8.8 m
•
kg, 64 ft
•
Ib)
T
R
.
.
48 Nm (4.8 m
•
kg, 35 ft
•
Ib)
T
R
.
.
88 Nm (8.8 m
•
kg, 64 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
LT
LT
LT
LT
LT
LT
LT
LT
LT
LT
5
1
2
6
5
4
3
18
11
9
8
10
13
15
17
20
19
(4)
16
14
12
7
6
To Next Page
