GENERATOR AND STARTER CLUTCH
5-39
EAS24480
GENERATOR AND STARTER CLUTCH
Removing the stator coil
Order Job/Parts to remove Q’ty Remarks
Left side cover
Refer to “GENERAL CHASSIS” on page
4-1.
Engine oil
Drain.
Refer to “CHANGING THE ENGINE OIL” on
page 3-11.
Drive pulley cover Refer to “BELT DRIVE” on page 4-69.
Left footrest assembly/Sidestand Refer to “ENGINE REMOVAL” on page 5-1.
1 Stator coil coupler 1 Disconnect.
2 Crankshaft position sensor coupler 1 Disconnect.
3 Damper cover 1
4 Generator cover damper 1
5 Left side cover bracket 1
6 Generator cover 1
7 Generator cover gasket 1
8 Dowel pin 2
9
Crankshaft position sensor/stator assembly lead
holder
1
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
6 Nm (0.6 m
•
kg, 4.3 ft
•
Ib)
New
New
New
New
LS
LS
LS
LT
LT
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
LT
9
10
8
8
7
11
5
2
1
4
3
6
(6)
New
E
(12)
To Next Page
