THROTTLE BODIES
7-8
Disassembling the intake manifold
Order Job/Parts to remove Q’ty Remarks
1 Front cylinder injector coupler 1 Disconnect.
2 Rear cylinder injector coupler 1 Disconnect.
3 Sub-wire harness 1
4Injector 2
5 Fuel pipe 1
6 Intake manifold 1
For assembly, reverse the disassembly pro-
cedure.
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
New
New
New
New
4
6
(4)
4
2
1
3
5
