ELECTRIC STARTING SYSTEM
8-12
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
8. Check the diode 2.
Refer to “CHECKING THE DI-
ODES” on page 8-93.
Replace the diode 2.
9. Check the starter relay.
Refer to “CHECKING THE RE-
LAYS” on page 8-91.
Replace the starter relay.
10.Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the main switch/immobilizer unit.
11.Check the engine stop switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the right handlebar switch.
12.Check the neutral switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the neutral switch.
13.Check the sidestand switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the sidestand switch.
14.Check the clutch switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the clutch switch.
15.Check the start switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the right handlebar switch.
16.Check the entire starting system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-7.
Properly connect or repair the starting sys-
tem’s wiring.
The starting system circuit is OK.
To Next Page
