ENGINE SPECIFICATIONS
2-8
5th 24/25 (0.960)
Main axle runout limit 0.08 mm (0.0032 in)
Drive axle runout limit 0.08 mm (0.0032 in)
Shifting mechanism
Shift mechanism type Guide bar
Shift fork guide bar bending limit 0.025 mm (0.0010 in)
Shift fork thickness 6.26–6.39 mm (0.2465–0.2516 in)
Air filter
Air filter element Oil-coated paper element
Fuel pump
Pump type Electrical
Model/manufacturer 292020–0100/DENSO
Maximum consumption amperage 4.6 A
Output pressure 392.0 kPa (56.8 psi) (3.92 kgf/cm²)
Fuel injector
Model/quantity INP-284/2
Manufacturer NIKK
Throttle body
Type/quantity ACW40/2
Manufacturer MIKUNI
ID mark 3D81 00
Throttle valve size #40
Fuel pressure 324 kPa (46.1 psi) (3.24 kg/cm²)
Throttle position sensor
Resistance 4.0–6.0 kΩ
Output voltage (at idle) 0.63–0.73 V
Fuel injection sensor
Crankshaft position sensor resistance 248–372 Ω
Intake air pressure sensor output voltage 3.75–4.25 V
Coolant temperature sensor resistance 290–354 Ω at 80 °C (176 °F)
Idling condition
Engine idling speed 950–1050 r/min
Intake vacuum 32.0–37.3 kPa (9.4–11.0 inHg) (240–280
mmHg)
Water temperature 90.0–100.0 °C (194.00–212.00 °F)
Oil temperature 70.0–80.0 °C (158.00–176.00 °F)
Throttle cable free play 4.0–6.0 mm (0.16–0.24 in)
Air temperature sensor resistance 290–354 Ω at 80 °C (176 °F)
