FUEL INJECTION SYSTEM
8-43
07 Vehicle speed pulse 0–999 Check that the number in-
creases when the rear
wheel is rotated. The num-
ber is cumulative and does
not reset each time the
wheel is stopped.
08 Lean angle sensor Remove the lean angle
sensor and incline it more
than 65 degrees.
• Upright 0.4–1.4
• Overturned 3.7–4.4
09 Fuel system voltage
(battery voltage)
Approximately 12.0 Set the engine stop switch
to “”, and then compare
with the actually measured
battery voltage. (If the bat-
tery voltage is lower, per-
form recharging.)
20 Sidestand switch Set on/off the sidestand
switch (with the transmis-
sion in gear).
• Sidestand retracted ON
• Sidestand extended OFF
21 Neutral switch Shift the transmission.
• Neutral ON
• In gear OFF
60 EEPROM fault code dis-
play
—
• No history 00
• History exists 01 or 02 (Cylinder fault code)
• (If both cylinders are defec-
tive, the display alternates
every two seconds.)
61 Malfunction history code
display
—
• No history 00
• History exists Fault codes 12-70
• (If more than one code
number is detected, the dis-
play alternates every two
seconds to show all the de-
tected code numbers.
When all code numbers are
shown, the display repeats
the same process.)
Diag-
nostic
code
No.
Item Meter display Checking method
