FUEL INJECTION SYSTEM
8-46
Fault code No. 12 Symptom No normal signals are received from the crankshaft posi-
tion sensor.
Diagnostic code No. ——
Order Item/components and probable
cause
Check or maintenance job Reinstatement
method
1 Installed condition of crankshaft posi-
tion sensor.
Check for looseness or pinching. Cranking the
engine.
2 Connections
• Crankshaft position sensor coupler
• Main wire harness ECU coupler
• Check the coupler for any pins
that may be pulled out.
• Check the locking condition of
the coupler.
• If there is a malfunction, repair it
and connect the coupler se-
curely.
3 Open or short circuit in wire harness. • Repair or replace if there is an
open or short circuit.
• Between the crankshaft position
sensor coupler and ECU cou-
pler.
(gray–gray)
(black/blue–black/blue)
4 Defective crankshaft position sensor. • Replace if defective.
Refer to “CHECKING THE
CRANKSHAFT POSITION
SENSOR” on page 8-96.
To Next Page
