FUEL INJECTION SYSTEM
8-58
Fault code No. 41 Symptom Lean angle sensor: open or short circuit detected.
Diagnostic code No. 08 Lean angle sensor
Order Item/components and probable
cause
Check or maintenance job Reinstatement
method
1 Connections
• Lean angle sensor coupler
• Wire harness ECU coupler
• Check the coupler for any pins
that may be pulled out.
• Check the locking condition of
the coupler.
• If there is a malfunction, repair it
and connect the coupler se-
curely.
Turning the
main switch to
“ON”.
2 Open or short circuit in lead. • Repair or replace if there is an
open or short circuit between
lean angle sensor coupler and
ECU coupler.
(blue–blue)
(yellow/green–yellow/green)
(black/blue–black/blue)
3 Defective lean angle sensor. • Execute the diagnostic mode.
(Code No. 08)
• Replace if defective.
Refer to “CHECKING THE
LEAN ANGLE SENSOR” on
page 8-96.
To Next Page
