4-20
Field Description
Where
Location of the LSA, used to indicate in which stage of the route
calculation the LSA is:
z Uninitialized: The LSA is not initialized or is originated by another
router.
z Clist: The LSA is on the candidate list.
z SpfTree: The LSA is in the SPF tree.
z SumAsb List: The LSA is in the AS border reachable to the
attached area.
z SumNet List: The LSA is in another area reachable to the
attached area.
z Inter List: The LSA is in another area.
z Sum Infinity: The LSA is in an unreachable area.
z Ase List: The LSA is outside the AS and is reachable.
z Ase Infinity: The LSA is outside the AS and is unreachable.
z Nssa List: The LSA is in an NSSA.
z Nssa Infinity: The LSA is in an unreachable NSSA.
<Sysname> display ospf lsdb ase
OSPF Process 1 with Router ID 1.1.1.1
Link State Database
Type : ASE
Ls id : 10.0.0.0
Adv rtr : 2.2.2.2
Ls age : 87
Len : 36
Seq# : 80000001
Chksum : 0xb45d
Options : (DC)
Net mask : 255.0.0.0
Tos 0 metric: 1
E type : 2
Forwarding Address :192.168.0.37
Tag: 1
