3-8
(196.0.0.3, 228.0.0.0)
Protocol 0x20: PIMSM, Flag 0x4: SPT
Uptime: 00:10:49, Timeout in 196 sec
Upstream interface: Vlan-interface196, RPF neighbor: NULL
Downstream interface list:
Vlan-interface401, Protocol 0x100: SPT, timeout in 197 sec
Matched 1 (S,G) entry, 1 (*,G) entry, 0 (*,*,RP) entry
Table 3-4 display pim routing-table command output description
Field Description
Total 1 (*, G) entry; 1 (S, G) entry,0 (*,*,RP) entry
Total number of (S, G), (*, G) and (*, *, RP)
entries in the PIM routing table
(*, 228.0.0.0) A (*, G) entry in the PIM routing table
RP Rendezvous point
Protocol PIM mode (PIM-SM or PIM-DM)
Flag
Flag of (S, G) or (*, G) entry in the PIM routing
table:
z SPT: The (S, G) entry is on the SPT.
z RPT: The (S, G) or (*, G) entry is on the RPT.
z WC: Indicates the (*, G) entry.
z LOC: The switch is connected with the
multicast source directly.
Uptime Time when the entry exists
Timeout in 197 sec The table entry will expire in 197 seconds.
Upstream interface Incoming interface
Upstream neighbor Upstream neighbor
RPT neighbor
z For the (*, G) entry, when this switch is an
RP, RPF neighbor field of the (*, G) entry is
Null.
z For the (S, G) entry, when this switch is
directly connected with the source, is an RP,
RPF neighbor field of the (S, G) entry is Null.
Downstream interface list List of downstream interfaces
display pim rp-info
Syntax
display pim rp-info [ group-address ]
