3.Press [TOGGLE ON/OFF] to enable or disable the check digit.
NOTE: The [TOGGLE ON/OFF] key is displayed only when the
cursor is positioned next to BAR CODE CHECK DIGIT.
4.Press [SETUP] to return to the OPERATION SETUP Screen.
Figure 5.17: Computer Setup Screen
The [COMPUTER SETUP] key is used to display the COMPUTER
SETUP Screen (see Figure 5.17) and the following soft key labels:
REINIT INTERFACE
STOP TRANSMISS
TOGGLE ON/OFF
RETURN
The CELL-DYN 3000 can transmit data to an on-line computer
(Laboratory Information System). Data may be transmitted automatically
as each sample is run or at the operator’s request. The CELL-DYN 3000
also can receive patient information transmitted to it by the on-line
computer.
REINIT
INTERFACE
STOP
TRANSMISS
TOGGLE
ON/OFF
RETURN
COMPUTER SETUP
Ready
Dec 08 1992
Operator ID
Sequence #
16:13
734
0070
OFF
OFF
OFF
OFF
OFF
8
1
0
0.3
9600
Auto-transmission of ALERTED parameter data
Auto-transmission of NON-ALERTED parameter data
Auto-transmission of ALERTED graph data
Auto-transmission of NON-ALERTED graph data
Transmission CTS enabled
Transmission Data bits (7, 8)
Transmission Stop bits (1, 2)
Transmission Parity (0=None, 1=Odd, 2=Even)
Transmission time out (0.1 to 9.9)
Computer Baud Rate (300, 600, 1200, 2400, 4800, 9600)
1
2
3
4
5
COMPUTER
SETUP
To Next Page
