5-102 CELL-DYN 3000 System Operator’s Manual
9140240E — May 1995
Operating Instructions Chapter 5
When the [DATA LOG] key is pressed, the DATA LOG Screen and the
following soft key labels are displayed:
EDIT ID*
DISPLAY SPECIMEN
FIND SPECIMEN
REJECT FROM X-B**
CUSTOMIZE DATA LOG
TRANSMIT DATA
PRINT DATA LOG
MAIN
* This key is displayed only if the cursor is positioned next to a
patient record. (See Figure 5.36.)
** This key is displayed if the sequence number of the patient
record is preceded by a B. (See Figure 5.36.)
The [EDIT ID] key is used to edit the Specimen ID from the DATA
LOG Screen. When the [EDIT ID] key is pressed, the cursor moves into
the <SPECIMEN ID> field and all key labels are blank. Edits are saved
by pressing the Enter key on the keyboard.
NOTE: The [EDIT ID] key is available only when the cursor is
positioned next to a Patient Record. It is not available for
Background or QC records.
DATA
LOG
EDIT
ID
