5-108 CELL-DYN 3000 System Operator’s Manual
9140240E — May 1995
Operating Instructions Chapter 5
Predetermined groups of parameters, called Standard Groups, may be
selected by pressing the [STANDARD GROUPS] key. Figure5.40
shows the CUSTOMIZE DISPLAY FOR DATA LOG Screen with the
standard groups displayed. The following soft key labels are displayed
when the [STANDARD GROUPS] key is pressed:
WBC GROUP
RBC GROUP
PLT GROUP
DIFF GROUP
CUSTOM PLACEMENT*
CUSTOMIZE PRINTOUT
RETURN
* The [CUSTOM PLACEMENT] key is used to return to the
CUSTOMIZE DISPLAY FOR DATA LOG Screen for
operator-selected placement.
Figure 5.40 shows the WBC Group placed in GROUP 1, the RBC Group
placed in GROUP 2, the PLT Group placed in GROUP 3 and the Diff
Group placed in GROUP 4.
When each soft key is pressed, the designated parameter group is placed
in the position indicated by the cursor.
STANDARD
GROUPS
