Abov MC97F60128 User Manual

205
MC97F60128
ABOV Semiconductor Co., Ltd.
T8ISR (Timer 8 Interrupt Status Register) : 4096H (XSFR)
7
6
5
4
3
2
1
0
IOVR
IBTM
ICMA
ICMB
ICMC
–
–
–
R/W
R/W
R/W
R/W
R/W
–
–
–
Initial value : 00H
IOVR
Timer 8 Compare Match or Timer 8 Overflow Interrupt Status, Write '0' to this bit for
clear. Write ‘1’ has no effect.
0
Compare match or Overflow no occurrence
1
Compare match or Overflow occurrence
IBTM
Timer 8 Bottom Interrupt Status, Write ‘0’ to this bit for clear. Write ‘1’ has no effect.
(In the Back-to-Back mode)
0
Bottom no occurrence
1
Bottom occurrence
ICMA
Timer 8 PWM A-ch Match Interrupt Status, Write ‘0’ to this bit for clear. Write ‘1’ has no
effect.
0
PWM A-ch match no occurrence
1
PWM A-ch match occurrence
ICMB
Timer 8 PWM B-ch Match Interrupt Status, Write ‘0’ to this bit for clear. Write ‘1’ has no
effect.
0
PWM B-ch match no occurrence
1
PWM B-ch match occurrence
ICMC
Timer 8 PWM C-ch Match Interrupt Status, Write ‘0’ to this bit for clear. Write ‘1’ has no
effect.
0
PWM C-ch match no occurrence
1
PWM C-ch match occurrence
T8MSK (Timer 8 Interrupt Mask Register) : 4097H (XSFR)
7
6
5
4
3
2
1
0
OVRMSK
BTMMSK
CMAMSK
CMBMSK
CMCMSK
–
–
–
R/W
R/W
R/W
R/W
R/W
–
–
–
Initial value : 00H
OVRMSK
Control Timer 8 Overflow Interrupt
0
Disable compare match or overflow interrupt
1
Enable compare match or overflow interrupt
BTMMSK
Control Timer 8 Bottom Interrupt
0
Disable bottom interrupt
1
Enable bottom interrupt
CMAMSK
Control Timer 8 Compare Match or PWM A-ch Match Interrupt
0
Disable PWM A-ch match interrupt
1
Enable PWM A-ch match interrupt
CMBMSK
Control Timer 8 PWM B-ch Match Interrupt
0
Disable PWM B-ch match interrupt
1
Enable PWM B-ch match interrupt
CMCMSK
Control Timer 8 PWM C-ch Match Interrupt
0
Disable PWM C-ch match interrupt
1
Enable PWM C-ch match interrupt
