MC97F60128
ABOV Semiconductor Co., Ltd.
SFCMD (Serial Flash Command Register) : 40B7H (XSFR)
7
6
5
4
3
2
1
0
SFCMD7
SFCMD6
SFCMD5
SFCMD4
SFCMD3
SFCMD2
SFCMD1
SFCMD0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
SFCMD[7:0]
Serial Flash Command Data.
VPADDR1 (Voice Prompt Address Register 1) : 40B8H (XSFR)
7
6
5
4
3
2
1
0
VPAR23
VPAR22
VPAR21
VPAR20
VPAR19
VPAR18
VPAR17
VPAR16
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
VPAR[23:16]
Voice Prompt Address MSB-byte.
VPADDR2 (Voice Prompt Address Register 2) : 40B9H (XSFR)
7
6
5
4
3
2
1
0
VPAR15
VPAR14
VPAR13
VPAR12
VPAR11
VPAR10
VPAR9
VPAR8
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
VPAR[15:8]
Voice Prompt Address Mid-byte.
VPADDR3 (Voice Prompt Address Register 3) : 40BAH (XSFR)
7
6
5
4
3
2
1
0
VPAR7
VPAR6
VPAR5
VPAR4
VPAR3
VPAR2
VPAR1
VPAR0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
VPAR[7:0]
Voice Prompt Address LSB-byte.
The VPADDR[23:0] is the start address of a voice prompt or voice prompt table in a
serial flash and can access up to 16M-bytes.
VPSIZE1 (Voice Prompt Size Register 1) : 40BBH (XSFR)
7
6
5
4
3
2
1
0
VPSZ23
VPSZ22
VPSZ21
VPSZ20
VPSZ19
VPSZ18
VPSZ17
VPSZ16
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
VPSZ[23:16]
Voice Prompt Size MSB-byte.
VPSIZE2 (Voice Prompt Size Register 2) : 40BCH (XSFR)
7
6
5
4
3
2
1
0
VPSZ15
VPSZ14
VPSZ13
VPSZ12
VPSZ11
VPSZ10
VPSZ9
VPSZ8
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
VPSZ[15:8]
Voice Prompt Size Mid-byte.
