VPSIZE3 (Voice Prompt Size Register 3) : 40BDH (XSFR)
7
6
5
4
3
2
1
0
VPSZ7
VPSZ6
VPSZ5
VPSZ4
VPSZ3
VPSZ2
VPSZ1
VPSZ0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
VPSZ[7:0]
Voice Prompt Size LSB-byte.
The VPSIZE[23:0] is the size of a voice prompt to play continuously
in a serial flash.
VPINF1 (Voice Prompt Inform Register 1) : 40BEH (XSFR)
7
6
5
4
3
2
1
0
VPINF15
VPINF14
VPINF13
VPINF12
VPINF11
VPINF10
VPINF9
VPINF8
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
VPINF[15:8]
Voice Prompt Inform High-byte.
VPINF2 (Voice Prompt Inform Register 2) : 40BFH (XSFR)
7
6
5
4
3
2
1
0
VPINF7
VPINF6
VPINF5
VPINF4
VPINF3
VPINF2
VPINF1
VPINF0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
VPINF[7:0]
Voice Prompt Inform Low-byte.
The VPINF[15:0] is the voice prompt information.
SFDDNO (Serial Flash Dummy and Data Number) : 40C7H (XSFR)
7
6
5
4
3
2
1
0
DUMY3
DUMY2
DUMY1
DUMY0
–
RDNO2
RDNO1
RDNO0
R/W
R/W
R/W
R/W
–
R/W
R/W
R/W
Initial value : 00H
DUMY[3:0]
The number of dummy for serial flash interface. The number of dummy is (n). Where n
= 0, 1, 2, ----- and 15.
RDNO[2:0]
The number of data to read from a serial flash. The number of data to read is (n+1).
Where n = 0, 1, 2, ----- and 7.
Ex) If n = 7, the voice prompt table data are 8-bytes to read from a serial flash.
