6240B DC Voltage Current Source/Monitor Operation Manual
4.2.4 HOLD Key (Trigger Mode)
4-4
4.2.4 HOLD Key (Trigger Mode)
Switches the source and measurement trigger mode.
4.2.5 LIMIT Key (Limiter Setting)
Switches between the source value setting screen and the limit value setting screen.
4.2.6 MENU Key (Parameter Setting)
Pressing the MENU key displays the parameter group setting screen.
Select parmeters from A) SOURCE to M) SYSTEM in the Category level menu with or .
For more information on setting parameters and the setting method, refer to Section 2.2.3, "Menu Opera-
tion."
SOURCE Sets source-related common elements.
PLS Base Sets the base value at pulse source.
Suspend V Sets the output voltage in Suspend.
Suspend Z Sets the output impedance in Suspend.
HiZ: The output current limit is set to 300 nA, so the output
impedance increases.
LoZ: The output current limit is set to the current limit value
at voltage source or 300 digits in the current range (100
digits in the 3 uArange) at current source, so the output
impedance decreases.
Source mode AUTO HOLD
DC/Pulse Repeats source and measurement within
the period time of the time parameter.
The sampling indicator turns ON during
measurement.
Executes source and measure-
ment with trigger input.
The HOLD indicator turns ON.
Sweep Repeats source and measurement within
the period time of the time parameter.
The sampling indicator turns ON during
measurement.
is displayed rotating during sweep.
Executes source and measure-
ment by one step with trigger
input, and pauses sweep.
The HOLD indicator turns ON.
The trigger mode cannot be changed during sweep.
