6240B DC Voltage Current Source/Monitor Operation Manual
6.3 GPIB
6-5
6.3 GPIB
6.3.1 Overview
GPIB (General Purpose Interface Bus) allows external control of the 6240B measurement function set-
tings, parameter settings and reading data, making it simple to configure an automated measurement sys-
tem.
As GPIB signals from the 6240B are electrically isolated inside the unit from the measurement signal sys-
tem, the connection of external devices does not affect the measured values.
The remote commands are the same as with USB.
• General specifications
Standard: IEEE-488.2
Code: ASCII code
Logic level: Logical 0 (High) +2.4 V min.
Logical 1 (Low) +0.4 V max.
Table 6-1 Interface Function
Code Function
SH1 Source Handshake capability
AH1 Acceptor handshake capability
T5 Basic Talker, unaddressed if MLA, Talk Only, serial poll
L4 Basic Listener, unaddressed if MTA
SR1 Service Request capability
RL1 Remote/Local switching capability
PP0 No Parallel Poll capability
DC1 Device Clear capability (The SDC and DCL commands can be used.)
DT1 Device Trigger capability (The GET command can be used.)
C0 No Controller capability
E2 Using tri-state bus drivers
