ADCMT 6240B User Manual

6240B DC Voltage Current Source/Monitor Operation Manual
5.2.3 Operations in Sweep Source Mode
5-12
5.2.3 Operations in Sweep Source Mode
The following table shows operations in the sweep source mode.
Table 5-4 Operations in Sweep Source Mode (1/2)
Sweep types Description Waveform
DC Sweep
Linear sweep
Sweeps with staircase waveforms
of the step value between the first
value and the last value.
Fixed sweep
Sweeps with waveforms of the
specified constant value the speci-
fied number of sample count.
Random sweep
Sweeps with waveforms of the
source values stored in the memory
from the start address to the stop
address.
2-slope linear sweep
Sweeps with staircase waveforms
of the 1st step value between the
first value and the middle value,
and sweeps with staircase wave-
forms of the 2nd step value
between the middle value and the
last value.
