6240B DC Voltage Current Source/Monitor Operation Manual
5.2.6 Measurement Function
5-34
5.2.6 Measurement Function
5.2.6.1 Measurement Function
The following measurement functions are available.
1. Voltage measurement function
2. Current measurement function
3. Resistance measurement function
For the voltage source function, resistance values are displayed by measuring current.
For the current source function, resistance values are displayed by measuring voltage.
For more information on resistance value calculation for the pulse source mode, refer to Section
5.2.6.3, "Measurement Delay Time and Measurement Value."
In one mode, the measurement function can be selected independently from the source function. In another
mode, the linked measurement function is set according to the source function.
Use E) MEASURE and 6) Mfunc Link to switch the mode.
When the link mode is selected, the measurement function is set as follows by changing the source func-
tion:
• Voltage source function/current measurement function VsIm
• Current source function/voltage measurement function IsVm
Also, immediately after the link mode is set, the measurement function changes according to the currently
set source function as shown above.
However, in the low-resistance measurement pulse source mode, the resistance measurement function is
always set regardless of the currently set source function.
NOTE: The resistance measurement function shows the following messages if it cannot normally execute
resistance value calculation.
Count Few: The current source value is below 20 digits, or current measurement value is
below 200 digits.
VSource=0: The voltage source value is 0.
HiLimit RM: HI limiter status
LoLimit RM: LO limiter status
