ADCMT 6240B User Manual

6240B DC Voltage Current Source/Monitor Operation Manual
2.2.1 Setting Source Value
2-18
3. Press or rotate one click counterclockwise.
The source range is automatically set to 3 V.
2.2.1.4 Setting Source Value Using Direct Input Mode
Press 123... key to turn to the direct input mode, and set the source value by using the numeric keys and
the unit key which are printed in green on the panel.
The following figures show the setting procedure.
Setting numeric values
1. Press 123....
The screen is half-brightness and indicates the direct input mode.
Cursor (blinking)
Cursor (blinking)
Half-brightness
