ADCMT 6240B - Menu Structure and Parameter Setting

6240B DC Voltage Current Source/Monitor Operation Manual
2.2.3 Menu Operation
2-27
2.2.3.2 Menu Structure and Parameter Setting
1) PLS Base Pulse source base value Numeric
VS +000.00 mV to 15.000 V
IS +00.000 mA to 1.0000 A
2) Suspend V Output voltage in Suspend
+000.00 mV to 15.000 V
Numeric
3) Suspend Z Output impedance in Suspend
HiZ/LoZ
Select
4) LMT Input How to set the limiter
Balance/Separate
Select
5) Response Output response
Fast/Slow
Select
MENU
A) SOURCE
(a)
Category level
Select level Input/Run level
B) SWEEP
Parameter
type
1) SweepType Sweep source mode
Linear/Fixed/Random/Linear 2
Select
2) SWP Range Source range for sweep
Auto/Fix
Select
3) Reverse Sweep reverse mode
Off/On
Select
4) Repeat Cnt Sweep repeat count
0 to 1000
Numeric
5) Rtrn Bias Returns to the bias value when sweep stops.
On/Off
Select
