6240B DC Voltage Current Source/Monitor Operation Manual
4.2.13 TRIG/SWP STOP Key (Trigger/Sweep Stop)
4-18
4.2.13 TRIG/SWP STOP Key (Trigger/Sweep Stop)
TRIG key: Functions as source or measurement trigger key.
SWP STOP key (SHIFT): Stops sweep.
4.2.14 UP Key (Source Range)
Increases the source range by one.
The source range setting mode is locked. (For more information on the LOCK status, refer to Section 4.2.3,
"FIT Key (Source Range).")
Source mode
Trigger mode
AUTO HOLD
DC source mode/pulse source mode/
low-resistance measurement pulse source mode
- Triggers measurement and pulse
source.
Sweep source mode/
pulse sweep source mode
Before sweep start Starts sweep. Starts sweep.
During sweep - Moves to the next step.
Source mode
Trigger mode
AUTO HOLD
DC source mode/pulse source mode/
low-resistance measurement pulse source mode
--
Sweep source mode/
pulse sweep source mode
Before sweep start - -
During sweep Stops sweep. Stops sweep.
